品牌 SICK/德國西克
型号：CQ35-25NPP-KW1
訂貨号：6020478
| Design: | Rectangular |  | |
| Dimensions (W x H x D): | 35 mm x 15 mm x 57.5 mm | |
| Sensing range Sn: | 25 mm | |
| Assured sensing range Sa: | 18 mm | |
| Installation type: | Non-flush | |
| Switching frequency: | 50 Hz | |
| Switching output: | PNP | |
| Output function: | Complementary | |
| Electrical wiring: | DC 4-wire | |
| Enclosure rating: | IP 67 1) | |
| Connection type: | Cable, 4-wire, 2 m 2) | |
| Adjustment: | Potentiometer, 270 ° , Sensitivity | |
| 1) According to EN 60529 2) Do not bend below 0 °C | |
| Mechanics/electronics | |||
| Housing material: | Plastic | |
| Supply voltage: | 10 V DC ... 36 V | |
| Ripple: | ≤ 10 % 1) | |
| Voltage drop: | ≤ 2.5 V DC 2) | |
| Power consumption: | ≤ 10 mA 3) | |
| Time delay before availability: | ≤ 100 ms | |
| Hysteresis: | 4 % ... 20 % | |
| Repeatability: | ≤ 5 % 4) 5) | |
| Temperature drift (of Sr): | ± 10 % | |
| EMC: | According to EN 60947-5-2 6) | |
| Output current Ia: | ≤ 200 mA | |
| Cable material: | PVC | |
| Conductor cross-section: | 0.34 mm² | |
| Short-circuit protection: | | |
| Reverse polarity protection: | | |
| Power-up pulse protection: | | |
| Shock/vibration: | 30 g, 11 ms / 10 ... 55 Hz, 1 mm | |
| Ambient operating temperature: | -25 °C ... +75 °C | |
| Housing cap material: | PC | |
| Sensing face material: | Plastic | |
| UL File No.: | NRKH.E191603 | |
| 1) Of Ub 2) At Ia max 3) Without load 4) Of Sr 5) Ub and Ta constant 6)In EMC critical applications, conducted interference levels may lie in the frequency range of the oscillator. This can cause changes to the output signal.(see operating instructions) | |
| Reduction factors | |||
| Note: | The values are reference values which may vary | |
| Metal: | 1 | |
| Water: | 1 | |
| PVC: | Ca. 0.4 | |
| Oil: | Ca. 0.25 | |
| |
| Installation note | |||
| Remark: | Associated graphic see "Installation" | |
| A: | 35 mm | |
| B: | 35 mm | |
